· GroupⅡA,groupⅡB,groupⅡC of explosive gas environments,zone1 and zone2.
· GroupⅢA,groupⅢB,groupⅢC of combustible dust environments,zone21 and zone22.
· Die-casting alloy shell with high pressure electrostatic powder spray,high strength and corrosion resistance.
· Flameproof enclosure with spigot joints and threaded joints,reliable explosion-proof performances.
· Silicone rubber sealed,excellent performance of protection and ageing-resistance,adapt to kinds of awful environments.
· High-quality LED,high luminous efficiency,good color rendering,anti-impact and vibration resistance.
· Non-imaging secondary optical design,energy-efficient lighting,optional light distribution,such as wide,narrow,asymmetric.
· Constant current drive,wide range input,isolated input/output,intelligent protective circuit,run reliably.
· Variety installation types,meet all kinds of lighting needs.
型号Type | AK-LBTR140(LT) | AK-LBTR200(LT) |
系统功率Power | 140W | 200W |
输入电压Input Voltage | AC110~264V 50~60Hz | |
配光Light Distribution | 宽光 Wide Beam窄光 Narrow Beam | |
系统输出System Output | ≥13500lm | ≥18000lm |
系统光效System Luminous Efficency | ≥95lm/W | ≥90lm/W |
显色指数Color Rendering Index | ≥80 | |
色温Color Temperature | 2700~6500K | |
透明罩Transparent Cover | 高强度钢化玻璃 Tempered Glass | |
进线口螺纹Cable Gland Thread | G3/4” | |
电缆外径Cable External Diameter | 8~12mm | |
防护等级Degree of Protection | IP66 | |
防腐等级Degree of Corrosion-proof | WF2 | |
防爆标志Ex-mark | Ex d ll C T6 GbEx tD A21 IP66 T80℃ | |
重量Weight | 8.9kg | |
执行标准Implementing Standard | GB3836.1 GB3836.2 GB12476.1 GB12476.5 |
序号S/N | 型号Type | 功率Power | 环境温度Environment Temperature | 应急Emergency |
1 | AK-LBTR140-WB | 140W | -20℃~55℃ | - |
2 | AK-LBTR140-NB | 140W | -20℃~55℃ | - |
3 | AK-LBTR200-WB | 200W | -20℃~40℃ | - |
4 | AK-LBTR200-NB | 200W | -20℃~40℃ | - |
5 | AK-LBTR140-LT-WB | 140W | -45℃~55℃ | - |
6 | AK-LBTR140-LT-NB | 140W | -45℃~55℃ | - |
7 | AK-LBTR200-LT-WB | 200W | -45℃~40℃ | - |
8 | AK-LBTR200-LT-NB | 200W | -45℃~40℃ | - |
