Explosion Proof
Your current position: Home > PRODUCTS > Explosion Proof
PRODUCTS#FANWEI
· GroupⅡA,groupⅡB, groupⅡC of explosive gas environments,zone2.
· GroupⅢA,groupⅢB,groupⅢC of combustible dust environments,zone21 and zone22.
PRODUCTS#TEDIAN
· Die-casting alloy shell with high pressure electrostatic powder spray,high strength and corrosion resistance.
· Ex type of protection”n”,reliable explosion-proof performance.
· Silicone rubber sealed,excellent performance of protection and ageing-resistance,adapt to kinds of awful environments.
· High-quality LED,high luminous efficiency,good color rendering,anti-impact and vibration resistance.
· Non-imaging secondary optical design,asymmetric light distribution,effectively expanded irradiation range,improved illumination uniformity.
· Constant current drive,wide range input,isolated input/output,intelligent protective circuit,run reliably.
PRODUCTS#JISHU
型号Type | AK-LBFN95(LT) | AK-LBFN135(LT) | AK-LBFN200(LT) | AK-LBFN300(LT) |
系统功率Power | 95W | 135W | 180W | 240W |
输入电压Input Voltage | AC110~264V 50~60Hz | |||
系统输出System Output | 11400lm | 15000lm | 19800lm | 31500lm |
系统光效System Luminous Efficency | ≥120lm/W | ≥110lm/W | ≥110lm/W | ≥130lm/W |
显色指数Color Rendering Index | ≥80 | |||
色温Color Temperature | 2700~6500K | |||
透明罩Transparent Cover | 高强度钢化玻璃 Tempered Glass | |||
进线口螺纹Cable Gland Thread | M25×2 | |||
电缆外径Cable External Diameter | 8~12mm | |||
防护等级Degree of Protection | IP66 | |||
防腐等级Degree of Corrosion-proof | WF2 | |||
防爆标志Ex-mark | Ex nR ⅡC T4/T5/T6 GcEx tD A21 IP66 T130℃/T95℃/T80℃ | |||
重量Weight | 12.9kg | |||
执行标准Implementing Standard | GB3836.1 GB3836.8GB12476.1 GB12476.5 | |||
PRODUCTS#XUAN
序号S/N | 型号Type | 功率Power | 环境温度Environment Temperature | 应急Emergency |
1 | AK-LBFN95 | 95W | -20℃～55℃ | - |
2 | AK-LBFN135 | 135W | -20℃～55℃ | - |
3 | AK-LBFN200 | 180W | -20℃～55℃ | - |
4 | AK-LBFN300 | 240W | -20℃～40℃ | - |
5 | AK-LBFN95-LT | 95W | -45℃～55℃ | - |
6 | AK-LBFN135-LT | 135W | -45℃～55℃ | - |
7 | AK-LBFN200-LT | 180W | -45℃～55℃ | - |
8 | AK-LBFN300-LT | 240W | -45℃～40℃ | - |
