Ceiling
PRODUCTS#FANWEI
Industrial factory with low to
medium ceiling, warehouse, supermarket,
stadium etc.
PRODUCTS#TEDIAN
· Die-casting alloy shell with high
pressure electrostatic powder spray, high strength and corrosion resistance .
· Integrated design ， external power,
attractive appearance ， sufficient heat
dissipation.
· High-quality
LED chips, high luminous efficiency, good color rendering,
anti-impact and vibration resistance .
· Optical grade
light diffuser plate ， high light transmittance, evenly distributed lighting output,
no glare.
· Constant
current drive, wide range input, intelligent protective
circuit, stable operation, ultra-long life .
· Excellent EMC design, no interferes to electric power systems or
other electrical equipment s.
· Variety installation types, flexible optional.
PRODUCTS#JISHU
| 型号 Type | BY-60 | BY-80 |
| 功率 Power | 60W | 80W |
| 输入电压 Input Voltage | 100～240VAC 50~60Hz | |
| 系统输出 System Output | 7500lm | 10000lm |
| 系统光效 System Luminous Efficiency | ≥125lm/W | ≥125lm/W |
| 显色指数 Color Rendering Index | ≥80 | |
| 色温 Color Temperature | 2700～6500K | |
| 防护等级 Degree of Protection | IP42 | |
| 环境温度 Ambient Temperature | -40℃～55℃ | -40℃～40℃ |
| 重量 Weight | 2kg | 2.8kg |
| 执行标准 Implementing Standard | GB7000.1 GB7000.201 GB17625.1 GB17743 | |
PRODUCTS#XUAN
| 序号Serial number | 型号Type | 功率Power | 环境温度 Ambient Temperature |
| 1 | BY-60 | 60W | -40℃～55℃ |
| 2 | BY-80 | 80W | -40℃～40℃ |
PRODUCTS#TIHUAN
Can replace 150W metal halide lamps
and other similar traditional lamps with equivalent.
